FFS Heavy-duty PE Tubular Bags

No.014
FFS Heavy-duty PE Tubular bags have high durability and good thickness uniformity because they were manufactured with high performance polyethylene (PE) material through an advanced multi-layered co-extrusion blown film process. Form-fill-seal (FFS) system is the integrated solution where the bag is cut and formed from a continuous reel, then filled and sealed before emerging as a finished pack. FFS system can improve efficiency of the filling operations and decrease labor costs.
Download
View all downloads
  • FFS Heavy-duty PE Tubular Bags,JM PACKAGING,FFS Heavy-duty PE Tubular Bags
  • FFS Heavy-duty PE Tubular Bags,Jiangmei Packaging,FFS Heavy-Duty PE Tubular Bags Factory - Jiangmei Packaging
  • FFS Heavy-duty PE Tubular Bags,Jiangmei Packaging,FFS Heavy-Duty PE Tubular Bags Factory - Jiangmei Packaging
  • FFS Heavy-duty PE Tubular Bags,Jiangmei Packaging,FFS Heavy-Duty PE Tubular Bags Factory - Jiangmei Packaging
  • FFS Heavy-duty PE Tubular Bags,Jiangmei Packaging,FFS Heavy-Duty PE Tubular Bags Factory - Jiangmei Packaging

Description

This type of bag is designed for FFS fully automated packaging production line. The bag is made of single material and can be directly recycled.

※Applicable to industrial use: Plastic material, chemical raw material, chemical fertilizer, organic compound fertilizer

FFS Heavy-Duty PE Tubular

Specification

Width:

35~65 cm

Thickness:

0.12~0.22 mm

Roll Diameter :

100~150 cm

Printing:

1~6 colors

Anti-slip Treatment:

Static Friction Coefficient > 0.5

Ink:

comply with Restriction of Hazardous Substance (RoHS) inspection standard

Bag material:

comply with “ Sanitation Standard for Food Utensils, Containers and Packages”

 Customizing Options

◎Bag Type:Gusseted type

◎Anti-Slip embossing strip

◎Micro-perforated degassing

◎UN Certificate

Product Feature

1. Bag Type:

Flat type / Gusseted type

2. Anti-Slip embossing strip:

Increase stability during stacking by two anti-slip embossing strips on both sides of bags. (front & back).

3. Micro-perforated degassing:

After treatment of precise micro-perforated equipment, bags are leak-proof and degassing to increase efficiency of packaging operation

4. UN Certificate:

Comply with International Maritime Dangerous Goods (IMDG) Code inspection standard and apply UN certification for client’s bags.






Product Overview

FFS heavy-duty PE tubular bags are the pack a form-fill-seal line makes for itself. Instead of loading pre-made sacks into a filler, the machine draws a continuous PE tube off a reel and forms, fills and seals the bag in one automatic cycle — the bag only becomes a bag at the moment it is needed.

The film is blown from high-performance polyethylene on our own lines, printed, and wound as a tube. Because the pack is built from a single material, an empty bag can go straight into the PE recycling stream: there is no laminate to separate and no second substrate to strip out.

These are FFS packaging line bags for plants filling powders, pellets and granules into bags of up to 50 kg on a fully automated line. On a normal shift they behave like a consumable — a reel goes on the unwind, the line runs at its own pace, and closed, dust-tight packs come off the discharge ready for the palletizer, with no empty-bag handling and no separate closing step at the end of the line.

Key Selling Points

  • One continuous cycle. Forming, filling and sealing happen without a stop, so throughput is set by the filler rather than by empty-bag handling.
  • Heavy-duty co-extruded PE. Strength and puncture resistance come from the film structure, not from thickness alone, so the reel stays workable on the machine.
  • No side seam to fail. The bag is cut from a continuous tubular reel rather than folded and joined, so the wall holding a 25 kg fill has no join running down its length — the line where a filled sack usually starts to leak.
  • Steady gauge, fewer rejects. Thickness that holds across the roll keeps sealing temperature and jaw pressure where you set them, which shows up as fewer rejects at high line speed.
  • Dust and moisture barrier. The closed PE wall keeps fine powder in and humid air out through months of storage and a sea container — which is what most FFS bags for chemicals and fertilizer grades are bought for.
  • Set to your machine and your load. Bag size, film recipe and print are matched to your filler and your product, which is why FFS bags for cement and resin pellets do not leave here on the same film build.

Tubular Construction & Line Cycle

  1. Reel on the unwind. The printed tubular reel is mounted on the machine. Roll diameter and winding are set so the film pulls evenly at line speed, with no slack and no drag.
  2. Forming and cutting. The machine measures the tube to the bag length, cuts it and opens the top ready for filling, and holds that section through the next steps.
  3. Filling. Product is dosed into the open bag while the machine still holds it — the fill and the seal happen in one uninterrupted sequence, with no transfer to a second station.
  4. Sealing. The top is closed by the machine's jaws in the same cycle. Sealing is against the same film face every time, so one setting holds for the shift instead of being chased.
  5. Discharge and palletizing. The closed, dust-tight pack leaves the machine ready to stack or stretch-wrap; nothing else has to be done to it before it reaches the pallet.
  6. Where the film comes from. Co-extruded FFS film bags are blown as one multi-layer tube, so the layer that seals, the layer that carries toughness and the layer that takes print are all set before the reel reaches your line. A change of load is handled at the film stage rather than by adding a second material.

Specifications

Property Value
Bag format Tubular, formed and cut on the FFS line
Bag type Flat or gusseted
Bag width 35–65 cm
Film thickness 0.12–0.22 mm
Roll diameter 100–150 cm
Printing 1–6 colors
Anti-slip treatment Static friction coefficient above 0.5
Ink Complies with the Restriction of Hazardous Substances (RoHS) inspection standard
Bag material Complies with the Sanitation Standard for Food Utensils, Containers and Packages
Typical load 10–50 kg
Material Co-extruded polyethylene, single material
Product code No. 014

Customizing Options

  • Bag type. Flat or gusseted, both of which run on the same machine. The choice changes the filled shape and the way the packs sit on a pallet, so settle it before printing is booked.
  • Bag size and film build. Width and film thickness are set inside the published range to match your jaw set and your load. Co-extruded FFS film bags are matched to the product as well — an abrasive mineral powder and a free-flowing pellet do not get the same structure. Send the product, fill weight and machine details.
  • Anti-slip embossing. Two strips, one on each face, added on request. Confirm them with the rest of the specification so they are included in the same run as your print.
  • Micro-perforated degassing. Added on request and set to the product. Tell us the fill weight and how freely the powder flows and we will propose the perforation pattern for your approval.
  • UN certification. Requested at the quoting stage for dangerous-goods shipments; we apply against the IMDG Code on your own bags. It is the paperwork sea carriers expect before a container is accepted for loading. Tell us the goods and the shipping route.
  • Printing. 1 to 6 colors on the film face. Send artwork in the format we confirm with you and a proof comes back before production begins.
  • Roll build. Roll diameter and roll length are set to your unwind, so a reel change lands where your shift plan wants it instead of mid-run.

Product Features

Flat or gusseted build.

A flat bag uses the least film per pack and stacks tightly against its neighbors; a gusseted bag opens into a squarer block that carries more volume for light, bulky powders and sits more steadily once filled. Both run on the same machine, so the choice is about how the finished pack behaves on the pallet rather than about the line.

Anti-slip embossing strips.

Two strips are embossed into the bag, one on the front face and one on the back. They lift the static friction coefficient above 0.5, so each layer of a stack grips the one beneath it instead of sliding when the stack is built tall or a trailer brakes hard on the way to the port.

Micro-perforated degassing.

Precise perforating equipment puts a controlled pattern of micro-holes through the film. Air pushed out by the product escapes while the product itself stays in, so the pack comes off the line flat and dense instead of ballooning, and the filler is not working against back-pressure. It matters most with fine, air-trapping powders — FFS bags for chemicals are the usual place where the perforation pattern has to be tuned rather than taken off the shelf.

Putting the options together.

Most specifications combine two or three of these: a gusseted bag with anti-slip strips for a tall stack, or a flat bag with degassing for a dense powder. Each addition is checked against the load and the pallet pattern before the reel is made.

Applications

Application What the bag carries
Cement and dry mortar Cement, gypsum, putty powder and dry-mix mortars
Chemicals Powder and pellet chemical raw materials — the standard job for FFS bags for chemicals
Fertilizers Powder and granular fertilizer, including organic compound grades
Plastic resins Resin pellets and masterbatch
Minerals and building materials Mineral powders and construction material mixes
Industrial granules Salt, sugar and similar granular goods
Food applications Food powders, with food-contact documentation available on request

Ordering & Delivery

  1. Tell us what goes in the bag. Product type, bulk density and target fill weight decide the film build and whether the degassing option is worth having. It is the difference between quoting FFS bags for cement and quoting a light pellet pack — same machine, different reel.
  2. Send your machine data. Filler make and model, the bag width your jaw set accepts, the sealing method and the reel geometry your unwind takes. That is how FFS packaging line bags avoid a trial-and-error first reel.
  3. Confirm the options that apply. Bag type, anti-slip strips, degassing and print all affect tooling time and price; settle the list before production starts so nothing has to be added mid-run.
  4. Approve the print. 1 to 6 colors. Send artwork, we return a proof, and production begins on your approval.
  5. Plan a first-article run. Ask your sales contact about sample availability and a trial reel on your own line — seal settings and pack shape are quickest to confirm under production conditions.
  6. Agree quantity, packing and delivery. Roll length per reel, pallet or carton packing, order quantity, lead time, payment terms and shipping terms are confirmed for each order with your sales contact.
  7. Repeat orders. Keep the approved specification on file and the next order can be raised against the same film build, print and roll build.

Technical Support & Model Matching

Involving our technical team early makes specification easier. Tell us what you are packing, how your line or handling process works and what your machine expects, and we will help you match the right option in our range to your operation, including the settings that suit your conditions. If something does not run as expected, we work through the problem with you, suggest adjustments, and guide setup and first runs. Support continues after delivery, and we are glad to review requirements before you order.

FAQ

Q1. Can these bags be used for cement and dry mortar?

Yes — cement, dry mortar, gypsum and putty powders are a standard job for them. FFS bags for cement are usually specified with the anti-slip strips because the filled packs are stacked deep, and with a heavier film build than a light pellet pack. The sealed PE wall keeps the fine dust inside the pack and humid air outside it.

Q2. How do they handle chemical powders and pellets?

Chemical raw materials are one of the main uses, and the film build follows the product: pellets want toughness and a clean drop, fine powders want a structure that fills and settles without trapping air, and the reel is matched to how the product behaves at the filler. That is why two chemical packs for the same machine can still use different film.

Q3. Will they run on our existing FFS machine?

That is what they are made for. FFS packaging line bags are specified against your machine: the bag width your jaw set accepts, the film thickness your sealing window handles, and the roll diameter your unwind takes. Send the filler model and your current reel dimensions and we will confirm the match before a reel is made.

Q4. How is the film structure chosen for a product?

By what you pack and how your line runs. Co-extruded FFS film bags are blown from several PE layers together, so toughness can be added where a dense or abrasive product needs it, the seal can be protected where the jaws run hot, and the print face stays clean. Tell us the product, fill weight and sealing method and we will confirm the structure.

Q5. Do the bags keep moisture out during storage and export?

Yes. Once the top seal is made the bag is closed, so humid air and container condensation have no path in during warehouse storage or sea freight. The outside of the pack also stays clean, which matters when bags sit in an open yard or are re-handled at the port.

Q6. Does the micro-perforation weaken the bag or let moisture in?

The perforations are made on precise equipment and are small enough that the product stays in while displaced air gets out. They work as a venting path rather than a hole in the barrier, and the film around them is unchanged. If your goods are moisture-sensitive and you want a fully closed wall, say so when the specification is agreed and we will confirm the right configuration.
